Ubiquiti

Ubiquiti (USW-16-POE) UBIQUITI UniFi SWITCH 16 POE, 16 (8 PoE+), 2x SFP, 42W, FANLESS, RACK-MOUNT, 1YR

(No reviews yet) Write a Review
SKU:
USW-16-POE
MPN:
USW16POE
Availability:
In Stock
  • Ubiquiti (USW-16-POE) UBIQUITI UniFi SWITCH 16 POE, 16 (8 PoE+), 2x SFP, 42W, FANLESS, RACK-MOUNT, 1YR
  • Ubiquiti (USW-16-POE) UBIQUITI UniFi SWITCH 16 POE, 16 (8 PoE+), 2x SFP, 42W, FANLESS, RACK-MOUNT, 1YR
  • Ubiquiti (USW-16-POE) UBIQUITI UniFi SWITCH 16 POE, 16 (8 PoE+), 2x SFP, 42W, FANLESS, RACK-MOUNT, 1YR
  • Ubiquiti (USW-16-POE) UBIQUITI UniFi SWITCH 16 POE, 16 (8 PoE+), 2x SFP, 42W, FANLESS, RACK-MOUNT, 1YR
  • Ubiquiti (USW-16-POE) UBIQUITI UniFi SWITCH 16 POE, 16 (8 PoE+), 2x SFP, 42W, FANLESS, RACK-MOUNT, 1YR
MSRP: $639.00
$627.00 Inc. GST
MSRP: $580.91
$570.00 Ex. GST
— You save $12.00
Frequently bought together:

Description

Description
Manufacturer: Ubiquiti Inc.
Manufacturer Part Number: USW-16-POE
Manufacturer Website Address: http://www.ui.com
Brand Name: Ubiquiti
Product Model: USW-16-POE
Product Name: USW-16-POE Ethernet Switch
Product Type: Ethernet Switch
Technical Information
Features:
  • Access Control List
  • IGMP Snooping
  • Flow Control
  • Port Mirroring
  • Virtual LAN (VLAN)
  • Loop Protection
  • Reset Button
Interfaces/Ports
Total Number of Network Ports: 16
Network (RJ-45): Yes
Port/Expansion Slot Details:
  • 8 x Gigabit Ethernet Network
  • 8 x Gigabit Ethernet PoE+
  • 2 x Gigabit Ethernet Expansion Slot
Media & Performance
Media Type Supported:
  • Twisted Pair
  • Optical Fiber
Ethernet Technology: Gigabit Ethernet
Network Technology:
  • 10/100/1000Base-T
  • 1000Base-X
Maximum Data Transfer Rate: 128 MB/s
I/O Expansions
Total Number of Expansion Slots: 2
Expansion Slot Type: SFP
Number of SFP Slots: 2
Network & Communication
Layer Supported: 2
Networking Standards: IEEE 802.1x
Management & Protocols
Manageable: Yes
Power Description
PoE (RJ-45) Port: Yes
PoE Budget: 42 W
Input Voltage:
  • 120 V AC
  • 230 V AC
Frequency:
  • 50 Hz
  • 60 Hz
Power Source: AC/DC
Power Consumption: 60 W
Physical Characteristics
Product Material: SGCC Steel
Compatible Rack Unit: 1U
Form Factor: Rack-mountable
Height: 44 mm
Width: 442 mm
Depth: 200 mm
Weight (Approximate): 2.80 kg
Miscellaneous
Application/Usage:
  • Network
  • Wireless Access Point
  • Security Camera
Additional Information:
  • Switching Capacity: 36 Gbps
  • Total Non-Blocking Throughput: 18 Gbps
  • Forwarding Rate: 27 Mpps
  • Supported VLANs: 1,000
  • MAC Address Table Size: 8,000
  • Packet Buffer Size: 0.5 MB
  • Management: Ethernet, AR
  • Heat Dissipation: 61.4 BTU/hr
  • Supported Rack Depth: 400~1200 mm (15.7-47.2")
  • LCM Display: 1.3" touchscreen
  • ESD Protection: Air: ± 16kV, contact: ± 12kV
  • Ambient Operating Temperature: -5 to 40° C (23 to 104° F)
  • Ambient Operating Humidity: 10 to 90% noncondensing
  • NDAA Compliant: Yes
  • LACP Port Aggregation: Yes
  • STP & RSTP: Yes
  • Advanced IGMP Configuration (Querier, Fast Leave, Router Port): Yes
  • MAC-Based ACLs & Device Isolation: Yes
  • DHCP Snooping & Guarding: Yes
  • Egress Rate Limit: Yes
  • Storm Control: Yes
  • Multicast & Broadcast Rate Limiting: Yes
  • MAC Address Blocking: Yes
  • IP-Based ACLs & Network Isolation: Yes
  • MAC-Based Port Restriction: Yes
  • Port Isolation: Yes
  • Jumbo Frames: Yes
  • LLDP-MED: Yes
  • Voice VLAN: Yes
  • Virtual Network Override: Yes
