Name: FORTINET (FAN-612N) FORTIANTENNA-612N
Brand: Fortinet
SKU: FAN-612N
Availability: OutOfStock

FORTINET (FAN-612N) FORTIANTENNA-612N

(No reviews yet) Write a Review

SKU:

FAN-612N

UPC:

94922443540

MPN:

FAN612N

Availability:

END OF LIFE

Description
Warranty Information

Description

Description
Manufacturer:	Fortinet, Inc
Manufacturer Part Number:	FAN-612N
Manufacturer Website Address:	http://www.fortinet.com
Brand Name:	Fortinet
Product Line:	FortiAP
Product Model:	FAN-612N
Product Name:	FAN-612N External Antenna (N type)
Marketing Information:	FAN-612R and FAN-612N 120° Sector FAN-612R and FAN-612N are a dual-band 2-element 120 degree sector antenna for use in 802.11n MIMO applications. The antenna provides coverage of 2.4 to 2.5 GHz and 4.9 to 5.9 GHz in a single antenna radome. The light weight and durable construction and UV-protected radome made of plastic allow both indoor and outdoor installation. Usage scenarios include: This antenna is also suitable for coverage of large rectangular areas like shopping centers, courtyards and hallways. Two FAN-612R can be used with the FAP-223B to provide full dual-band dual-radio 802.11a/b/g/n MIMO coverage. Outdoor coverage can be provided by placing FAP-223B indoor and the antenna outdoor on the opposite side of the wall. FAN-612N can be used with the FAP-222B to provide full dual-band dual-radio 802.11a/b/g/n MIMO coverage.
Product Type:	Antenna
Technical Information
Directivity:	Directional
Frequency Band Type:	UHF SHF
Operating Frequency Range:	2.4 GHz to 2.5 GHz 4.9 GHz to 5.9 GHz
Antenna Gain:	5 dBi
Impedance:	50 Ohm
Features:	UV Protected Water Proof
Interfaces/Ports
Connector Type:	N-Type
Physical Characteristics
Height:	200.7 mm
Width:	200.7 mm
Diameter:	31.8 mm
Form Factor:	Wall Mount
Weight (Approximate):	260 g
Miscellaneous
Application/Usage:	Outdoor Wireless Data Network
Compatibility:	Fortinet FAP-223B Wireless Access Point
